System and script improvements

Postby PetrS » 26 Sep 2014, 09:05

size=150System and script improvements/size
Version 0.1.75+

ub^ operator/b/u
This operator is equal to upper index or POWER function.
It can be useful for complex exponents.

ubdouble<in, 3>/b/u
This declaration of numeric variable allows you to define units and precision used for this variable.
This is useful in functions, because local variables of function are not displayed in VariableGrid -> you can't modify them manually.

ubIO.LayoutIndex/b/u
This system variable contains index of current Layout.
Value is automatically updated to be valid also in ExternCLC.
If the calculation is not drawn (just calculated), IO.LayoutIndex has value '-1'.
See attached example for more details.
Attachments
DoubleDeclaration.cls
(31.12 KiB) Downloaded 168 times
LayoutIndex_Extern.cls
(30.13 KiB) Downloaded 155 times
LayoutIndex_Master.cls
(32.71 KiB) Downloaded 158 times
Ing. Petr Slepicka

Engineering calculations online - EuroCode, AISC, statics
Automate your static calculations today!

PetrS
Site Admin
Posts: 181
Joined: 11 Jul 2014, 13:55
[phpBB Debug] PHP Warning: in file [ROOT]/vendor/twig/twig/lib/Twig/Extension/Core.php on line 1107: count(): Parameter must be an array or an object that implements Countable

Re: System and script improvements

Postby PetrS » 16 Oct 2014, 13:03

Attachments
Ing. Petr Slepicka

Engineering calculations online - EuroCode, AISC, statics
Automate your static calculations today!
